IP Phone 75
XTS-IP / XTSc-IP Station User Guide March 2007
Soft Key Displays
Idle State
Misc-Tone State (Busy Tone)
Incoming CO Call State (Talk State)
Outgoing CO Call State (Talk State)
Key 1Key 2Key 3
PICKUP VM1 LNR
ANS-CALL UA-CALL SNR
PERS-MSG BGM (N/A) P-PKP1
ALLPG-IN ALLPG-EX UNA
BIN FWD ALL FWD N/A-FWD
BSY-FWD B/NA-FWD CLR-FWD
H-MODE T-MODE P-MODE
BKL-OFF BKL-ON BKL-INUSE
Key 1Key 2Key 3
MSG CALL-BK CAMP-ON
Key 1Key 2Key 3
CONF REC FLASH
Key 1Key 2Key 3
CONF REC FLASH
