VOLTCRAFT VC950 User Manual

Battery level indicator; the bars indicates the battery level.
Symbol for the diode test
Symbol for the acoustic continuity tester
AC Symbol for AC power
DC Symbol for DC power
mV Millivolt (exp.-3)
V Volt (unit of electric voltage)
A Ampere (unit of electric current)
mA Milliampere (exp.-3)
μA Microampere (exp.-6)
Hz Hertz(unitoffrequency)
kHz Kilo Hertz (exp.3)
MHz Mega Hertz (exp.6)
% Percentage for duty cycle measurement
°C Degrees Celsius
°F DegreesFahrenheit
Ω Ohm (unit of electric impedance)
kΩ Kilo Ohm (exp.3)
MΩ Mega Ohm (exp.6)
nF Nanofarad (exp.-9, unit of electric capacity, symbol )
µF Microfarad (exp.-6)
mF Millifarad (exp.-3)
Symbol for the capacity measuring range
Warning symbol for dangerous voltage
Bargraf bar display
Symbol for the integrated fuses
PrObE Warning for missing or incorrectly connected test lead
42
