VOLTCRAFT VC950 - Scanning Rate and HFR Accuracy; Temperature, Continuity, Diode Test Specifications

64
Scanning rate (duty factor)
Range Accuracy
20.0% ~ 80.0% ±(0.13%+10)
Overload protection 1000 V
Sensitivity: 5 Vpp - 10 Vpp
Signal: rectangular (5 Hz to 10 kHz)
HFR (Low-Pass Filter)
Range Accuracy
Identical
with ACV
(1.3%+8)at40Hz~400Hz
Overloadprotection1000V,cut-offfrequency:800Hz(-3dB)
Temperature
Range Accuracy
-200,0 to +10,0 °C
±(1.3%+20)
+10,1 to +1200,0 °C
±(1.3%+10)
-328.0°F~50.0°F ±(1.3%+40)
50.1°F~2192.0°F ±(1.3%+20)
Overload protection 1000 V
Acoustic continuity tester
Test voltage Resolution
approx. 2.5 V 0.1Ω
Overloadprotection:1000V,<50Ωcontinuoussound.
Displayarea:1000.0Ω,testcurrentmax.0.1mA
Diode test
Test voltage Resolution
approx. ±2.5 V 0.001 V
Overloadprotection:1000V,testcurrentmax.±0.5mA,testfrequency
ca. 35 Hz
