Service and maintenance
134 Engine
VOE 2134355130
Changing oil
1 Place the machine in the service position.
2 Put a container (above 50 liter) under the protecting cap (E) at
the bottom of the engine oil pan.
3 Remove protecting cap (E) and attach drain hose (F) provided
as a service tool with machine.
4 Drain the oil.
5 Disconnect the hose and install the protecting cap.
6 Fill oil through oil filler cap.
Oil capacity when changing is approx. 46.4 liters (12.2 US gal) in-
cluding filters.
For oil grade, See on page 177.
Take care of waste oil/fluids in an environmentally safe way!
E
F
S82313
