Volvo EC330B - Working Ranges

Specifications
Working ranges 189
VOE 2134355130
Working ranges
Direct fit bucket
Description Unit
6.2 m Boom
20' 4"
6.45 m Boom
21' 2"
2.6 m Arm
8'6"
2.6 m Arm
8'6"
3.2 m Arm
10' 6"
3.9 m Arm
12' 10"
A. Maximum digging reach
mm
ft-in
10480
34' 5"
10540
34' 7"
11060
36' 3"
11700
38' 5"
B.
Maximum digging reach on
ground
10250
33' 8"
10320
33' 10"
10850
35' 7"
11500
37' 9"
C. Maximum digging depth
6700
21' 12"
6770
22' 3"
7370
24' 2"
8080
26' 6"
D. Maximum cutting height
10110
33' 2"
10100
33' 2"
10260
33' 8"
10530
34' 7"
E. Maximum dumping height
6860
22' 6"
7170
23' 6"
7360
24' 2"
7630
25' 0"
F.
Maximum vertical wall digging
depth
4880
16' 0"
4900
16' 1"
5290
19' 5"
5920
19' 5"
G. Maximum front swing radius
4160
13' 8"
4390
14' 5"
4340
14' 3"
4320
14' 2"
H. Minimum digging depth (8' level)
6530
21' 5"
6570
21' 7"
7190
23'7"
7930
26' 0"
S82248
G
E
D
H
F
C
B
A
