Operating instructions
90 Selecting track shoe
VOE 2134355130
Selecting track shoe
Grouser Use Precautions when using
A
600 mm
Rocky ground,
normal soil
Travel in low speed when traveling on rough ground with obstacles
such as large boulders and fallen trees.
B
700 mm
800 mm
Soft ground Travel in high speed only on flat ground. When it is impossible to
avoid travelling over obstacles, lower the travel speed to approxi-
mately half of low speed.
WARNING!
Cannot be used on rough ground where there are large
obstacles such as boulders and fallen trees.
C
900 mm
Extremely soft
ground
(swampy
ground)
Use only for ground where “A” and “B” are impossible to use. Travel
in high speed only on flat ground. When it is impossible to avoid
travelling over obstacles, lower the travel speed to approximately
half of low speed.
WARNING!
Cannot be used on rough ground where there are large
obstacles such as boulders and fallen trees.
