Service and maintenance
Oil bath Air cleaner (option) 143
VOE 2134355130
4 Dry thoroughly with compressed air
5 Inspect body
– Each time the oil cup is serviced, inspect lower portion of body
assembly and center tube for structural integrity. Replace bro-
ken, cracked, or missing parts.
6 Reassemble
– Reassemble filter assembly (if used) with serviced oil cups and
air cleaner body. Be sure the oil cup is tight to body assembly.
S82273
S82274
S82275
