Volvo EC330B - Plates and Decals

Presentation
14 Plates and decals
VOE 2134355130
8 Lifting capacity table
Shoe 600 mm (kg)
∗ Power booster ON
L
A
0.0m 1.5m 3.0m 4.5m 6.0m 7.5m 9.0m Maximum
B
2.6 m
7.5 m
∗8870 7040
6.0 m
∗10780 9060 9690 6260 ∗8590 5600
4.5 m
∗15940 13380 ∗12380 8600 9480 6070 7610 4870
3.0 m
∗20110 12190 13090 8090 9200 5830 7090 4500
1.5 m
∗15570 11550 12620 7690 8960 5600 6960 4380
0.0 m
∗20140 11390 12370 7470 8800 5460 7180 5460
-1.5 m
∗14290 ∗14290 20240 11430 12310 7420 8770 5430 7870 4910
-3.0 m
∗25570 23930 ∗19860 11630 12440 7530 9430 5860
-4.5 m
∗20920 ∗20920 ∗16010 12030 ∗12040 8230
3.2 m
7.5 m
∗7920 6580 ∗7120 6240
6.0 m
∗8050 6510 ∗6920 5130
4.5 m
∗12290 ∗12290 ∗9890 8910 ∗8710 6290 7200 4650 ∗6990 4540
3.0 m
∗15880 12700 ∗11600 8360 9400 6010 7070 4530 6590 4220
1.5 m
∗18490 11830 12840 7890 9120 5750 6930 4400 4670 4110
0.0 m
∗19440 11480 12500 7590 8910 5570 6830 4310 6630 4190
-1.5 m
∗13820 ∗13820 ∗19200 11420 12370 7480 8820 5490 7160 4510
-3.0 m
∗16340 ∗16340 ∗21900 ∗21900 ∗17960 11550 12420 7520 8880 5550 8300 5210
-4.5 m
∗20830 ∗20830 ∗15380 11870 ∗11540 7760 ∗9990 6790
-6.0 m
3.9 m
9.0 m
∗6060 ∗6060
7.5 m
∗8000 6760 ∗5650 5340
6.0 m
∗8370 6620 ∗6980 4780 ∗5520 4480
4.5 m
∗10230 9090 ∗9230 6350 7240 4660 ∗5560 3990
3.0 m
∗16260 13020 ∗12290 8440 9440 6010 7050 4490 ∗5760 3710
1.5 m
∗19870 12840 12840 7840 9070 5680 6860 4310 5760 3600
0.0 m
∗8400 ∗8400 20030 11200 12360 7420 8790 5420 6700 4170 5870 3650
-1.5 m
∗8840 ∗8840 ∗13010 ∗13010 19760 10990 12110 7210 8630 5280 6630 4100 6250 3870
-3.0 m
∗13770 ∗13770 ∗18880 ∗18880 19810 11030 12080 7180 8610 5260 7060 4370
-4.5 m
∗19650 ∗19650 ∗27110 23010 ∗19370 11290 12260 7340 8810 5440 8760 5410
-6.0 m
∗20590 ∗20590 ∗14990 11830 ∗11060 8120
S84243
8
5800 kg
Pressure
34.34 MPa
(350 bar)
Kg
B
A
S84240C
S84241
6.45 m
L
