Volvo EC330B - Page 17

Presentation
Plates and decals 15
VOE 2134355130
Shoe 23.6 in (lb)
∗ Power booster ON
L
A
0.0 ft 5.0 ft 10.0 ft 15.0 ft 20.0 ft 25.0 ft 30.0 ft Maximum
B
8' 6"
25 ft
∗20050 19990 ∗19670 15890
20 ft
∗23460 19510 20800 13450 ∗18980 12490
15 ft
∗34150 28910 ∗26800 18570 20390 13080 16860 10790
10 ft
∗43120 26370 28170 17480 19820 12560 15660 9940
5ft
∗38070 24910 27160 16600 19290 12080 15340 9660
0ft
43230 24520 26600 16110 18950 11780 15830 9920
-5 ft
∗32520 ∗32520 43320 24590 26470 16000 18900 11730 17390 10860
-10 ft
∗57130 51140 ∗43020 25020 26760 16250 20950 13020
-15 ft
∗44960 ∗44960 ∗34250 25940 ∗26490 18580
10' 6"
25 ft
∗16010 14100 ∗15760 14040
20 ft
∗17650 14010 ∗15280 11440
15 ft
∗26390 ∗26390 ∗21430 19230 ∗18990 13560 ∗15400 10060
10 ft
∗34110 27460 ∗25090 18060 20260 12980 15210 9760 14570 9330
5ft
∗39890 25540 27640 17040 19650 12420 14920 9490 14280 9080
0ft
∗42110 24730 26900 16390 19210 12020 14730 9310 14630 9250
-5 ft
∗31280 ∗31280 ∗41640 24590 26610 16140 19020 11860 15820 9970
-10 ft
∗36620 ∗36620 ∗49630 ∗49630 ∗38910 24870 26730 16240 19180 12000 18420 11570
-15 ft
∗44880 ∗44880 ∗33070 25590 ∗24590 16790 ∗22040 15250
-20 ft
12' 1"
25 ft
∗17720 14490 ∗12520 11980
20 ft
∗18350 14240 ∗13560 10220 ∗12180 9980
15 ft
∗22170 19600 ∗20130 13680 15560 10020 ∗12240 8840
10 ft
∗34950 28120 ∗26600 18220 20330 12960 15170 9660 ∗12680 8210
5ft
∗42860 25540 27630 16930 19540 12250 14760 9280 12710 7960
0ft
∗19100 ∗19100 42910 24130 26580 16010 18930 11690 14440 8980 12940 8050
-5 ft
∗19720 ∗19720 ∗29390 ∗29390 42300 23640 26040 15540 18580 11380 14300 8850 13800 8560
-10 ft
∗30830 ∗30830 ∗42720 ∗42720 42410 23730 25980 15490 18560 11370 15650 9690
-15 ft
∗44210 ∗44210 ∗58790 49240 ∗41790 24310 26400 15850 19580 12100
-20 ft
∗43640 ∗43640 ∗31640 25570 ∗24340 18620
-25 ft
12790 lb
Pressure
34.34 MPa
(350 bar)
lb
B
A
S84240D
S84241A
21' 2"
L
