Volvo EC330B - Page 18

Presentation
16 Plates and decals
VOE 2134355130
Shoe 31.5 in (lb)
∗ Power booster ON
L
A
0.0 ft 5.0 ft 10.0 ft 15.0 ft 20.0 ft 25.0 ft 30.0 ft Maximum
B
8' 6"
25 ft
∗20050 20490 ∗19670 16310
20 ft
∗23460 20010 21410 13820 ∗18980 12850
15 ft
∗34150 29640 ∗26800 19060 21010 13450 17390 11120
10 ft
∗43120 27100 29010 17970 20430 12930 16170 10250
5ft
∗38070 25640 28000 17090 19910 12460 15840 9970
0ft
44570 25250 27450 16610 19570 12160 16350 10240
-5 ft
∗32520 ∗32520 44670 25330 27320 16500 19520 12110 17960 11210
-10 ft
∗57130 52550 ∗43020 25750 27610 16750 21620 13430
-15 ft
∗44960 ∗44960 ∗34250 26670 ∗26490 19120
10' 6"
25 ft
∗16010 14480 ∗15760 14430
20 ft
∗17650 14400 ∗15280 11780
15 ft
∗26390 ∗26390 ∗21430 19750 ∗18990 13950 ∗15400 10370
10 ft
∗34110 28220 ∗25090 18580 ∗20870 13370 15720 10070 15060 9640
5ft
∗39890 26300 ∗28380 17550 20290 12810 15430 9800 14760 9380
0ft
∗42110 25490 27780 16910 19850 12410 15240 9630 15140 9560
-5 ft
∗31280 ∗31280 ∗41640 25350 27480 16650 19660 12250 16360 10300
-10 ft
∗36620 ∗36620 ∗49630 ∗49630 ∗38910 25630 27610 16760 19820 12390 19030 11940
-15 ft
∗44880 ∗44880 ∗33070 26360 ∗24590 17310 ∗22040 15710
-20 ft
12' 1"
25 ft
∗17720 14860 ∗12520 12310
20 ft
∗18350 14610 ∗13560 10520 ∗12180 10270
15 ft
∗22170 20100 ∗20130 14050 16050 10320 ∗12240 9110
10 ft
∗34950 28850 ∗26600 18720 20940 13330 15660 9960 ∗12680 8480
5ft
∗42860 26280 28480 17420 20150 12620 15250 9580 13140 8220
0ft
∗19100 ∗19100 44250 24870 27430 16510 19540 12070 14920 9280 13380 8320
-5 ft
∗19720 ∗19720 ∗29390 ∗29390 43650 24370 26890 16040 19200 11760 14780 9150 14270 8850
-10 ft
∗30830 ∗30830 ∗42720 ∗42720 43760 24470 26820 15980 19180 11740 16170 10010
-15 ft
∗44210 ∗44210 ∗58790 50660 ∗41790 25050 27240 16350 20220 12480
-20 ft
∗43640 ∗43640 ∗31640 26300 ∗24340 19160
-25 ft
S84243
8
12790 lb
Pressure
34.34 MPa
(350 bar)
lb
B
A
S84240E
S84241A
21' 2"
L
