Presentation
12 Plates and decals
VOE 2134355130
Information and warning plates
The following depicts various warning and information texts that
may be affixed to the machine and their mounting location. The op-
erator must know and pay attention to the warning and safety in-
formation on each decal and plate. Decals / plates that are lost,
damaged, illegible, painted over or not clearly visible must be re-
placed immediately.
The part number (order number) of the respective plates / decals
can be found in the Parts Catalogue.
1 Do not start the engine
2 Safety locking
See Safety locking system on page 60.
3 Do not unscrew the recoil spring
See Inspecting and adjusting the track slack on page 166.
S82282
5
6
4
7
3
1
2
S80606
S82335
S80599
