9. Secure air pipe, transducer and cable to vehicle
• Use cable ties to support air pipe and sensor cable connections. Secure the connectors to
existing cables where possible
• Ensure that cable to cable connections are well supported
• Avoid running cables on or near sharp objects
• Keep cables away from hot components such as exhausts and engines
• Use cable ties to secure any excess cable to the chassis of the vehicle
Use cable protector to protect the cable at positions where it may be exposed to damage
Ensure that you make a note of the serial number of the sensor and the location on the
vehicle where it is installed.
10. Make a note of the serial number of the sensor and the position it is located on the vehicle, e.g.
SN: xxxx, rear left air circuit etc.
It is recommended that you use the system conguration table to record this information.
See “System conguration table” on page 68
