3. Putting into operation
■ Use a dry cloth to remove the corrosion protection that was applied to all exposed parts for
transport.
■ In the event of marine impregnation of exposed parts, it is recommended you spray them with oil,
allow it to work, and then remove the impregnation with a dry cloth.
■ Once set up properly (see the section on delivery and set up) connect the grounded plug directly to
a safety socket and the 230 V 50/60 Hz (optional 110 V 60 Hz) mains power supply.
■ Provision of sufficient coolant for the operation of a coolant system (optional).
■ Release the axis clamps and check the individual feed spindles for easy operation.
■ Check all electronic operating elements, for example, ON/OFF switch, emergency off switch,
potentiometer, bush protection hood, etc. for functionality.
4. Specifications regarding the machine
4.1 Identification of the model
The precise model designation of your machine can be found on the type plate attached to the
machine.
4.2 Noise emission declaration D2000
Noise emission declaration in accordance with DIN EN ISO 3744
Emission values in idle
Emission noise level at the workplace
at 50 % = 60.8 dB (A
at 100 % = 72.0 dB (A)
Sound power level
at 50 % = 70.4 dB (A)
at 100 % = 81.9 dB (A)
With an emission noise level as of 80 dB (A) at the workplace
ear defenders must be worn
