WABECO D2000 - Key for Circuit Diagram

68
16. Circuit diagram
16.3 Key for circuit diagram
Color-code by IEC 60757
BK Black PK Pink
BN Brown RD Red
BU Blue VT Violet
GN Green WH White
GY Grey YE Yellow
OG Orange YG Yellow/Green
M1 Main spindle motor
M6 Feed motor
N1 Power plug
N2 Motor plug
N4 Clamping bar
P1 Motor control board
P4 Feed board
R1 220 kΩ (ohm) potentiometers spindle speed
R2 10 kΩ (ohm) potentiometers spindle speed
S1 Emergency switch-off
S2 Main switch
S10
End switch chuck -cover
S11 Turn switch spindle right/left
S12 Feed direction
T1 Speedometer
T2 Thermistor
T3 Transformer
W1 Coil 1
W2 Coil 2
