21. Tensioning bracket with milling machine table (optional)
21.7 Drawing and legend
Part No. Items Order No. Description
1 1 Longitudinal skid (included in lathe)
2 1 51006831-00331 Tensioning bracket
3 1 51508322 Dust protection cover
4 1 Nut (included in lathe)
5 1 Washer (included in lathe)
6 1 16112500010000 Washer
7 1 16193300010030 Screw
8 2 16091300008010 Threaded pin
9 2 51004006-0002 Push piece
10 1 51003790-0001 Milling machine table
