6. Thread cutting and automatic feed
6.2 Use of change gears
Z/1“ 10 11 12 13 14 16 18 19 20
A1
34
34
34
34
34
34
34
34
34
A2 36 36 36 36 36 36 14
34*
18
C 20 22 24
26*
28 32 14 36 20
C1 32 32 32 32 32 32 32 32 32
D 120 120 120 120 120 120 120 120 120
F 140 120 140 140 140 140 120 140 120
Z/1“
22
24
26
28
30
32
34
36
A1 34 34 34 34 34 34 34 34
A2 18 24 18 18 24 18 18 14
C 22 32
26*
28 40 32 34 28
C1 32 32 32 32 32 32 32 32
D 120 120 120 120 120 120 120 120
F 120 140 140 140 140 140 140 140
