3-44 OM 25-3503 us – Edition 4.1 * * 2503_3503b330.fm
Operation
4 Mounting point B (lower).
5 Tighten screws C and lock nuts at the upper and lower left and right to 110 Nm (81
ft.lbs.).
Fig. 122: Lower mounting point
B
C
