5.18 Maintenance overview
Maintenance plan (Tier IV)
Daily maintenance (user)
Inspection work
(Check the following fluids and lubricants, check the oil levels after a test run and add oil if necessary)
Page
Check the fluids and lubricants (engine oil, engine coolant, hydraulic oil) 5-7, 5-8, 5-14
Check the radiator and hydraulic oil cooler for dirt, clean them if necessary 5-7
Lubricate the machine according to the lubrication plan 5-27
Check the water separator and fuel filter: drain water if necessary 5-4
Check the track tension and retension the tracks if necessary 5-19
Check the engine air intake 5-11
Check pin lock --
Check line fixtures --
Check the indicator lights and warning devices for correct function 3-14, 3-12
Check the swivel unit brake for correct function 3-84
Check the hydraulic couplings for dirt --
Check the threaded fittings of the protective structures (for example the cabin) for tightness --
Clean the lights/light system, signaling system --
Option
Check the acoustic warning device of the overload valve --
Easy Lock: check the acoustic warning system --
Lubricate the Powertilt according to the lubrication plan 5-32
Adjust the mirrors correctly, clean them and check them for damage, check the fastening screws and tighten them
if necessary
--
Leakage check
Check for tightness, leaks and chafing: pipes, flexible lines and threaded fittings of the following assemblies and
components. Repair if necessary
Page
Engine and hydraulic system 5-18
Traveling drive --
Cooling systems, heating and hoses (visual check) --
Option
Hydraulic quickhitch (Easy Lock) and Powertilt (hoses, valve) --
Visual check
Correct function; deformations, damage, surface cracks, wear and corrosion Page
Check the exhaust system for damage --
Check the insulating mats in the engine compartment for damage --
Check the cabin and protective structures for damage (for example the Front Guard, FOPS) --
Check the tracks for damage --
Check the travel gear for damage (for example the track rollers, insert rolling bearings) --
