Wacker Neuson 2503 User Manual

OM 25-3503 us – Edition 4.1 * 2503_3503b330.fm 3-65
Operation
☞ Raise the floor mat on either side.
☞ Remove screws F on either side.
Raise the machine as follows:
☞ Do not allow anyone to stay in the cabin, and close the doors and the engine cover.
☞ Slowly raise the cabin.
NOTICE
Inspect the cabin for damage as you raise it.
☞ Set down the cabin safely and ensure that it cannot tip over.
Fig. 159: Left cabin attachment
F
Fig. 160: Right side cabin attachment
F
Fig. 161: Crane-lifting
