Wacker Neuson 2503 User Manual

OM 25-3503 us – Edition 4.1 * 2503_3503b110.fm 1-5
Introduction
2503 with mechanical Neuson quickhitch
Bucket type
Width Capacity Weight
Bucket 260 mm (10 in)
0.036 m
3
(1.27 ft
3
)
38 kg (84 lbs)
Bucket 300 mm (12 in)
0.043 m
3
(1.52 ft
3
)
44 kg (97 lbs)
Bucket 400 mm (16 in)
0.059 m
3
(2.08 ft
3
)
52 kg (115 lbs)
Bucket 500 mm (20 in)
0.075 m
3
(2.65 ft
3
)
58 kg (128 lbs)
Bucket 600 mm (24 in)
0.091 m
3
(3.21 ft
3
)
67 kg (148 lbs)
Bucket
700 mm (28 in)
0.107 m
3
(3.78 ft
3
)
75 kg (165 lbs)
Ditch cleaning bucket 850 mm (33 in)
0.069 m
3
(2.44 ft
3
)
65 kg (143 lbs)
Ditch cleaning bucket 1000 mm (39 in)
0.080 m
3
(2.83 ft
3
)
74 kg (163 lbs)
Ditch cleaning bucket 1200 mm (47 in)
0.095 m
3
(3.35 ft
3
)
88 kg (194 lbs)
Offset bucket 850 mm (33 in)
0.073 m
3
(2.58 ft
3
)
110 kg (243 lbs)
Offset bucket 1000 mm (39 in)
0.087 m
3
(3.07 ft
3
)
121 kg (267 lbs)
2503 with hydraulic Easy Lock quickhitch
Bucket type
Width Capacity Weight
Bucket 300 mm (12 in)
0.042 m
3
(1.48 ft
3
)
43 kg (95 lbs)
Bucket 400 mm (16 in)
0.056 m
3
(1.98 ft
3
)
50 kg (110 lbs)
Bucket 500 mm (20 in)
0.070 m
3
(2.47 ft
3
)
60 kg (132 lbs)
Bucket 600 mm (24 in)
0.084 m
3
(2.97 ft
3
)
67 kg (148 lbs)
Ditch cleaning bucket 850 mm (33 in)
0.065 m
3
(2.30 ft
3
)
63 kg (139 lbs)
Ditch cleaning bucket
1000 mm (39 in)
0.078 m
3
(2.75 ft
3
)
72 kg (159 lbs)
Ditch cleaning bucket 1200 mm (47 in)
0.094 m
3
(3.32 ft
3
)
84 kg (185 lbs)
Offset bucket
850 mm (33 in)
0.062 m
3
(2.19 ft
3
)
103 kg (227 lbs)
Offset bucket
1000 mm (39 in)
0.073 m
3
(2.58 ft
3
)
110 kg (243 lbs)
Offset bucket
1200 mm (47 in)
0.088 m
3
(3.11 ft
3
)
121 kg (267 lbs)
