Wacker Neuson 2503 User Manual

OM 25-3503 us – Edition 4.1 * 2503_3503b110.fm 1-7
Introduction
3503 with hydraulic Easy Lock quickhitch
Bucket type
Width (in) Capacity Weight
Bucket 300 mm (12 in)
0.063 m
3
(2.22 ft
3
)
56 kg (123 lbs)
Bucket 400 mm (16 in)
0.083 m
3
(2.93 ft
3
)
64 kg (141 lbs)
Bucket 500 mm (20 in)
0.102 m
3
(3.60 ft
3
)
75 kg (165 lbs)
Bucket 600 mm (24 in)
0.120 m
3
(4.24 ft
3
)
85 kg (187 lbs)
Bucket 700 mm (28 in)
0.141 m
3
(4.98 ft
3
)
92 kg (203 lbs)
Bucket
800 mm (31 in)
0.160 m
3
(5.65 ft
3
)
103 kg (227 lbs)
Ditch cleaning bucket 1000 mm (39 in)
0.113 m
3
(4.00 ft
3
)
92 kg (203 lbs)
Ditch cleaning bucket
1200 mm (47 in)
0.135 m
3
(4.77 ft
3
)
106 kg (234 lbs)
Ditch cleaning bucket
1400 mm (55 in)
0.158 m
3
(5.58 ft
3
)
121 kg (267 lbs)
Offset bucket
1200 mm (47 in)
0.129 m
3
(4.56 ft
3
)
142 kg (313 lbs)
Offset bucket
1400 mm (55 in)
0.150 m
3
(5.30 ft
3
)
153 kg (337 lbs)
Equipment
Attachments Machine Weight
Mechanical Neuson quickhitch console 2503 14 kg (31 lbs)
Mechanical Neuson quickhitch console 3503 27 kg (60 lbs)
Hydraulic Easy Lock quickhitch console (HS 02) 2503 19 kg (42 lbs)
Hydraulic Easy Lock quickhitch console (HS 03) 3503 34 kg (75 lbs)
Hammer bracket HS 02/NE 16 2503 14 kg (31 lbs)
Hammer bracket HS 03/NE 16 3503 27 kg (60 lbs)
Hammer bracket HS 03/NE 22 3503 30 kg (66 lbs)
Hammer NE 16 2503/3503 150 kg (331 lbs.)
Hammer NE 22 3503 220 kg (485 lbs)
Easy Lock quickhitch console with Powertilt 3503 104 kg (229 lbs)
