OM 25-3503 us – Edition 4.1 * 2503_3503b110.fm 1-19
Introduction
Meaning
This label shows the forward travel direction.
Location
On either side of the undercarriage
Meaning
The CE mark means that the machine meets the requirements of the Machine Directive
and that the conformity procedure has been performed. The machine meets all the health
and safety requirements of the Machine Directive.
Location
On the type label
Meaning
Interval at which lubrication point must be lubricated.
Location
On upper carriage
Meaning
Position in which the ball-type cock must be during hammer/normal operation.
Location
On the hydraulic oil reservoir.
Meaning
The valve cover is opened with this Bowden cable.
Location
Under the operator seat.
Meaning
The engine cover is opened with this Bowden cable.
Location
Under the operator seat.
Fig. 36: Direction indicator
Fig. 38: Lubrication interval
9705591
Fig. 39: Ball-type cock
9705239G
Fig. 40: Opening the valve cover
Fig. 41: Opening the engine cover
