Operation G 150 / 180 / 240
wc_tx000867gb.fm 30
2.8 Warning Light
Location and
description
The amber warning light (d) is located on the metering panel. The light serves as a
pre-alarm and turns on prior to a potential engine fault condition. At the same time
that the light goes on, the LCD panel will begin blinking to indicate which engine
function is approaching its fault value.
Engine pre-
alarms
Fuel Level = 15%
High Temperature = 226°F
Low Oil Pressure = 20 psi
Time to Service = 250 hours
Shutdown = 5%
wc_
r005201
d
