Factory-Installed Options
wc_tx000880gb.fm 62
4.5 Temperature-Activated Shutters
The shutters (a) are mounted to the top of the generator enclosure.
The shutters are designed to keep the engine compartment warm, thus increasing
engine temperature during cold weather operation. The shutters are activated
through a wax-pellet actuator (b) that is connected to the generator's cooling
system. As radiator coolant warms, the wax-pellet actuator engages a linkage (c)
that opens the shutters. As the coolant cools, the shutters close.
4.6 Lockable Battery Disconnect
A lockable ON/OFF switch is available which disconnects the battery. A padlock
(not included) securely locks the switch in the OFF position. If equipped, the battery
disconnect switch is mounted to the upper skid beneath the access door on either
the right or left side of the machine.
NOTICE: Do not use the battery disconnect switch while the engine is running.
Damage to electrical components may occur.
