Wacker Neuson G 150

G 150 / 180 / 240 Schematics
wc_tx000879gb.fm 67
5.4 AC Schematic Components (G 150 / G 180)
Ref. Description Ref. Description
1 Electronic control board 13 Stator
2 Plug 4—line voltage inputs 14 Exciter
3 Plug 3—current transformer
inputs
15 Rectifier
4 Phase switch 16 Rotor main field
5 Main breaker 17 Generator (alternator)
6 Lug safety limit switch 18 Stator aux winding
7 Mechanical lugs 19 Stator main windings
8 GFI receptacle, 120V 21 Rotor
9 Circuit breaker, 120V 20A 22 Terminate at strip on generator
11 Potentiometer, 150K 23 Circuit breaker, 240V 50A
12 Voltage regulator 24 Receptacle, 240V 50A
