Operation G 150 / 180 / 240
wc_tx000867gb.fm 38
2.17 Remote run terminal block
Location
The remote run terminal block (i) is located just to the left of the convenience
receptacle circuit breakers.
Description
The remote run terminal block provides connection points for installation of a
remote start switch. When it is connected to a transfer switch, it allows the
generator to be used as a stand-by power supply.
Connections
When connecting a remote start switch or transfer switch, use the inner two
terminals on the remote run terminal block.
Note: The bonding bar between the ground connections must remain in place at all
times unless a qualified electrician determines otherwise.
wc
r005194
i
