WarmFlow Agentis Series User Manual

Page 109
11.6 Combustion Head Adjustment
If the heat output of the burner is to be changed from the factory default setting, then the
combustion head must be repositioned in order to maintain low NOx levels.
11.6.1 RDB 2.2 BX Adjustment
Adjustments on the basis of the required output can be made by rotating the adjustment knob (1
complete revolution = 1 millimetre adjustment).
The settings for the mid-range outputs are shown in the table below.
Model X (mm) D(mm)
FULLY CLOSED 10.0 10.0
RDB 2.2 BX 15/21 11.5 11.5
RDB 2.2 BX 21/27 14.5 14.5
RDB 2.2 BX 27/33 18.0 18.0

WarmFlow Agentis Series Specifications

General

Installation Type	Wall-mounted
Type	Condensing
Dimensions	700 x 400 x 300 mm
Efficiency	Up to 93%
Control	Digital
Heating Capacity	Varies by model
Warranty	5 years
