WarmFlow GS25A - Dimensions

TECHNICAL CHARACTERISTCS
TR05A140.B1107
9
110137163
285
132
730
HF
G
HR
14849 182 31
285
730
111.5187111.5
48.5 313 48.5
105
ON / OFF
3.2 Dimensions
LEGEND
HR HEATING RETURN 22mm
HF HEATING FLOW 22mm
G
GAS 22mm
SC CONDENSATE DRAIN 25mm
Figure 2: Dimensions
