MAINTENANCE INSTRUCTIONS
TR05A140.B1107
54
6.9 Parts lists
6.9.1 Main components
CODE DESCRIPTION
40200069 PRIMARY EXCHANGER ISOTHERM. 4+1 3+3 25KW
12240045 PUMP RSL 15/5-3-KU-CLF6 w/OPEN C1+C3
46270044 CONDENSATE TRAP
50360067 ELECTRONIC GAS VALVE
40360068 VENTURI
20370032 FAN PX128/203 230V/50Hz - PX2030
28432074 WASHER/OR CLIPS KIT FOR MULTIPLEX
28590015 WATER PRESSURE SWITCH PC 5411 BRASS
40735016 HTG CLIP SENSOR X PIPE 17/18 mm. BLUE
40735017 THERMO FUSE 102°C RED ISTMQ 1/4" 4X45
16766077 PRINTED CIRCUIT BOARD BMBC c/DISPLAY
18767002 PRINTED CIRCUIT BOARD KOND DT
44860006 SAFETY THERMOSTAT 95C° X EL.TB 1NT
28860014 WATER PRESSURE GAUGE M3A-ABS 40 0-4 G1/8C/D+C
18880019 TRANSFORMER AC1 230VAC 25HZ 39/3200Y
48950013 EXPANSION VESSEL LT.7 3/8"
12960039 3 BAR PRESSURE RELIEF VALVE -HTG CIRCUIT
Table 11: Short parts list
