OPTIONAL CONTROLS
TR05A140.B1107
56
7.1.2 S-Plan wiring schematic
Zero-volt Switching Circuit
Add more valves
& programmers
as required
Permanent Live
Boiler
Terminal Block
Heating Zone Hot Water Cylinder
Cylinder
Thermostat
Room
Thermostat
2-port
zone valves
Zone valve
microswitches
Neutral
Figure 53: S-Plan wiring schematic
