205
Table A-4 Physical Specifications
Item Specification
Wetted Surface Material 316 stainless steel, ruby, sapphire, fluorocarbon polymer
Controller Height: 7.19 inches (18.26 cm)
Depth: 21.75 inches (55.25 cm)
Width: 11.32 inches (28.75 cm)
Weight: 33 lb (15 kg)
Pump Height: 9.625 inches (24.4 cm)
Depth: 20.5 inches (52.1 cm)
Width: 11.125 inches (28.3 cm)
Weight: 60.2 lb (27.3 kg)
Table A-5 Optional Rheodyne 7725i Manual Injector Specifications
Item Specification
Syringe Needle Size Length: 2.0 inches (5.08 cm)
O.D: 0.028 inches (0.071 cm) (22 gauge)
Pressure Limit 6000 psi (420 kg/cm
2
)
Wetted Surface Material 316 stainless steeel, TFE
Sample Load Size Sample injections from 1 µL to 20 µL with no loop
change. Injector mounts directly to pump.
