Waters 600E System Modules 3
1.2 Waters 600E System Modules
This section discusses the major modules of the Waters 600E system:
• Waters 600 Controller
• Waters 600E Pump
1.2.1 Waters 600 Controller
The Waters 600 controller (Figure 1-2) automatically controls the eluent gradient, the flow
rate, column heating, external events, and sparging. You can configure the 600 Controller
as a PowerLine system controller or as a Gradient controller (see Section 1.3, PowerLine
Controller Features, and Section 1.4, Gradient Controller Features, for details on these
controller configurations).
Table 1-1 Waters 600E System
Module Description
Waters 600
Controller
Controls eluent gradient, flow rate, external events, and sparging
for the Waters 600E system.
Provides connection terminals and communication ports for oper-
ation with and control of external devices, such as detectors,
autosamplers, and data systems.
Waters 600E Pump Contains components required to blend and to deliver eluents
from the eluent reservoir bottles to the injector and column.
Consists of the pump with 225 µL or 100 µL volume pump heads,
eluent sparge valve assembly, eluent proportioning valve
assembly, manual injector, and vent valve.
Rheodyne 7725i
Manual Injector
Load/Inject Handle
Connects and disconnects the sample loading loop from the
system. Allows variable-volume injections from a fraction of a µL
to 20 µL without changing loops.
