Waters ACQUITY UPLC I-Class IVD - Page 76

C External Connections
76 July 7, 2014, 715003736IVD Rev. C
0−2V Analog 1 Out Outputs the analog signal to a device such as an
integrator or strip-chart recorder. Via the
MassLynx software, you can select one of the
following signals as the chart out signal:
•Flow rate
•System pressure
•Composition (%A, %B)
Gradient In Initiates the pumps to begin gradient operation
by contact closure input or 0-volt input.
Stop Flow In Allows you to stop the flow from the binary
solvent manager when an error condition or
hardware failure occurs on another system
module.
Switch 2 Out Used to send time-based contact closure signals
to external devices.
Switch 3 Out Used to send time-based contact closure signals
to external devices.
0−2V Analog 2 Out Outputs the analog signal to a device such as an
integrator or strip-chart recorder. Via the
MassLynx software, you can select one of the
following signals as the chart out signal:
•Flow rate
•System pressure
•Composition (%A, %B)
Binary solvent manager analog-out/event-in connections: (Continued)
Signal connection Description
