Table B–5: Sample organizer performance specifications
Feature Specification
Sample plate capacity Sample plate capacity is configured based on
the types and combinations of plates being
used:
• Maximum of 19 standard microtiter plates,
up to 15.5 mm high
• Maximum of nine intermediate height plates
(or 2-mL vial holders), up to 40.0 mm high
• Maximum of six deep well plates (or 4-mL
vial holders), up to 47.0 mm high
Maximum sample capacity Maximum of 7296 samples in nineteen 384-
well plates
Sample compartment temperature range 4.0 to 40.0 °C, settable to 0.1 °C increments;
maintains 19 °C below ambient with a
tolerance range between -2 and +4 °C
Temperature accuracy ±0.5 °C at sensor
Temperature stability ±1.0 °C at sensor
Table B–6: TVM performance specifications
Feature Specification
Column capacity Single column, 75 µm to 4.6 mm I.D. and up to
250 mm in length
Switching valves Two six-port, two-position valves with
independent programmable control
Column compartment temperature range Ambient +9.0 to 90.0 °C, settable to 0.1 °C
increments
(Column compartment temperature lower
range is equal to ambient +5° C)
Column compartment temperature accuracy ±0.5 °C at sensor
Column compartment temperature stability ±0.3 °C at sensor
Primary wetted materials DLC, PEEK blend, and 316 stainless steel
November 26, 2019, 715003588 Revision C
Page 90
