Overview 13
• Single-piece column compartment door and hinge assembly that allows
tubing to enter or exit the column compartment from all four sides.
• Columns with dimensions of up to 7.8 mm diameter.
When you specify the temperature via the operating software, thermoelectric
devices achieve the desired column temperature. The column heater/cooler’s
internal power supply provides the additional power required to operate the
thermoelectric heater/cooler engine circuit.
Door gasket
Compartment
door
Tubing guide
Drip tray
Compartment door clasp
Column clip rails
Temperature port
Column clip
Convection grid
