Figure 1–3: Example of a system core stack
Solvent bottle tray
Detector
Column heater
Sample manager
Solvent manager
The system includes a solvent manager, sample manager, column heater, detector (tunable
ultraviolet, photodiode array, evaporative light scattering, fluorescent, conductivity, refractive
index, or mass spectrometry), and an ACQUITY UPLC column.
Waters Empower chromatography software, UNIFI, or MassLynx mass spectrometry software
controls the system.
