5 External connections
See also: For information explaining how to connect chromatographic tubing, see Installation
recommendations for fittings.
Note: A Waters Technical Service representative unpacks and installs the system components.
Warning: To avoid spinal and muscular injury, do not attempt to lift a system module
without assistance.
If you must transport a system component, or remove it from service, request recommended
cleaning, flushing, and packaging procedures from Waters Technical Service.
5.1 Ethernet connections
The sample manager incorporates an internal Ethernet switch that accommodates the PC
(workstation) and as many as six system modules. Connect the shielded Ethernet cables from
each module to the electronic connections on the rear panel of the sample manager. The sample
manager is connected internally to the Ethernet switch.
Alternative: Some column modules connect to the sample manager using an interconnect (D-
sub) cable assembly.
August 8, 2016, 715005049 Rev. C
Page 66
