Requirement: If this is the first time you are using this system, you must define a new
system. For instructions, see the online Help.
5. Open the control panels and console.
See also: Monitoring from control panels and Opening the console
6. Prime the system.
See also: Priming the system
3.2 Opening the console
You can perform the following tasks in the console:
• Monitor system performance
• Specify settings for certain module parameters
• Run diagnostic tests
• View an interactive diagram of the module components
See also: The console online Help for additional information on how to perform these tasks.
3.2.1
To open the console from Empower software
1. From the Empower navigation bar, select Run Samples and then Control Panel.
Result: A control panel for each device in the system appears.
2. In the sample manager control panel, click Display console .
Alternative: Right-click the control panel for any module, and select Launch Console
from the menu that appears.
3.2.2
To open the console from MassLynx software
1. From the MassLynx window, click Inlet Method.
2. Click the Additional Status tab.
Result: A control panel for each device in the system appears.
3. In the sample manager control panel, click Display console .
Alternative: Right-click the control panel for any module, and select Launch Console
from the menu that appears.
