5.5.2 Connecting to a cart's electricity source
If your system includes the optional FlexCart or micro cart, follow this procedure to connect each
module to a power source.
Warning: To avoid electrical shock, observe these precautions:
• Use SVT-type power cord in the United States and HAR-type power cord, or better,
in Europe. For requirements elsewhere, contact your local Waters distributor.
• Inspect the power cord for damage, and replace it, if necessary.
• Power-off and unplug each module before performing any maintenance operation
on it.
• Connect each module to a common ground.
Recommendation: Use a line conditioner and uninterruptible power supply (UPS) for
optimum, long-term, input-voltage stability.
To connect to a cart's electricity source:
1. Connect the female end of the cart's electrical cables (included in the startup kit) to the
receptacle on the rear panel of each system module.
2. Connect the hooded, male end of the cart's electrical cables to the power strips on its back.
3. Connect each power strip's cable to a wall outlet operating on its own circuit.
5.6
Connecting signal cables
The rear panel of the module includes a removable connector that holds the screw terminals for
the I/O signal cables. The connector is keyed so that it can be inserted only one way.
Refer to the cable-connection label affixed to the rear panel of the module.
Required tools and materials
• 9/32-inch nut driver
• Flat-blade screwdriver
• Connector
• Signal cable
To connect the cables:
1. Insert the connector into the connector port on the module's rear panel.
