Technical Specications
8
CFW-11 | 8-3
Table 8.2 - Technical Specications of frame sizes F, G and H DC version fed from 436 to 713 Vdc (equivalent to a rectied
380 to 480 Vac three-phase voltage) for switching
Model
CFW11
0242 T 4
..DC..
CFW11
0312 T 4
..DC..
CFW11
0370 T 4
..DC..
CFW11
0477 T 4
..DC..
CFW11
0515 T 4
..DC..
CFW11
0601 T 4
..DC..
CFW11
0720 T 4
..DC..
CFW11
0760 T 4
..DC
CFW11
0795 T 4
..DC..
CFW11
0877 T 4
..DC..
CFW11
1062 T 4
..DC..
CFW11
1141 T 4
..DC..
Frame Size F G H
Number of Power Phases DC
Use with Normal Duty
(ND) Cycle
Rated Output Current
(1)
242 312 370 477 515 601 720 760 795 877 1062 1141
Overload
Current
(2)
[Arms]
1 min 266 343 407 525 567 662 792 836 875 965 1168 1255
3 s 363 468 555 716 773 900 1080 1140 1193 1316 1593 1712
Rated Switching Frequency [kHz] 2 2 2 2 2 2 2 2 2 2 2 2
Maximum Motor
(3)
[HP/kW] 200/150 250/185 300/220 400/300 400/300 500/370 600/440 650/480 700/515 750/560 950/700 1000/750
Rated Input Current 327 421 500 644 695 811 972 1026 1073 1184 1434 1540
Dissipated
Power [W]
Surface
Mounting
(4)
2098 3228 3679 4866 5235 5543 6672 8070 7625 8502 9438 10229
Flange
Mounting
(5)
515 693 750 1028 1140 1334 1366 1253 705 709 714 718
Use with Heavy Duty (HD)
Cycle
Rated Output Current
(1)
211 242 312 370 477 515 560 600 637 715 855 943
Overload
Current
(2)
[Arms]
1 min 317 363 468 555 716 773 840 900 956 1073 1283 1415
3 s 422 484 624 740 954 1030 1120 1200 1274 1430 1710 1886
Rated Switching Frequency [kHz] 2 2 2 2 2 2 2 2 2 2 2 2
Maximum Motor
(3)
[HP/kW] 175/132 200/150 250/185 300/220 400/300 400/300 450/330 500/370 550/400 600/440 750/560 800/590
Rated Input Current [Arms] 285 327 421 500 644 695 756 810 860 965 1154 1273
Dissipated
Power [W]
Surface
Mounting
(4)
1814 2481 3071 3743 4842 4719 5142 6341 6041 6805 7453 8271
Flange
Mounting
(5)
442 533 615 794 1062 1137 1060 1328 698 701 703 707
Surrounding air Temperature [ºC (ºF)]
-10...45 ºC
(14...113 ºF)
-10...40 ºC
(14...104 ºF)
RFI Filter Built-in
Weight [kg (lb)] 97 100 102 107 151 151 156 156 213 213 220 220
Availability of Option Kits
that can be Integrated
into the Product (refer
to the smart code in the
Section 2.5 HOW TO
SPECIFY THE CFW-11
MODEL (SMART CODE) on
page 2-14)
Safety Stop Yes
24 Vdc External
Control
Power Supply
Yes
