Operating instructions – AC SMART
ADVANCED
PLUG SOCKET
Charging current, max. 16 A 32 A 16 A 32 A
Width x height x depth 273 x 439 x 150 mm (167 mm incl. cover) 273 x 439 x 150 mm (167 mm incl. cover)
Weight
5.6 kg 6.9 kg 4.3 kg
Housing impact resistance rating IK10 IK10
Operating temperature -25 °C to +45 °C -25 °C to +45 °C
Storage temperature -25 °C to +70 °C -25 °C to +70 °C
Relative humidity during
operation
5 ... 95 % (non-condensing) 5 ... 95 % (non-condensing)
Relative humidity during storage 5 ... 95 % (non-condensing) 5 ... 95 % (non-condensing)
Degree of protection IP54 IP54
Pollution severity 3 3
Protection class I I
Phases 1… 3 1… 3
Rated voltage
207 ... 253 V / 360 ... 440 V 207 ... 253 V / 360 ... 440 V
Rated current
16 A
32 A 16 A 32 A
Rated impulse voltage 4 kV 4 kV
Insulation voltage 500 V 500 V
Overvoltage category III III
Mains frequency
50 / 60 Hz 50 / 60 Hz
Circuit breaker max.
1)
16 A
32 A
16 A
32 A
Charging voltage
230 / 400 V
230 / 400 V
230 / 400 V
230 / 400 V
Charging power, max.
11 kW
22 kW
11 kW
22 kW
Short circuit current C16/C32
(energy limit class 3)
6 kA 6 kA
AC residual current protective
switch
1)
Type A 30 mA Type A 30 mA
DC fault-current detection
integrated
6 mA 6 mA
Network design TN / TT / IT TN / TT / IT
Charging mode 3 3
Supported charging states A, B, C, E, F A, B, C, E, F
EMCclassication Class B Class B
Socket in accordance with
IEC 62196-1:2014 for charging
cable
–
Type 2
Plug in accordance with IEC
62196-1:2014 for charging cable
Type 2
–
Permitted set-up area indoor, outdoor indoor, outdoor
Static load/charge management
integrated
x x
Dynamic load/charge manage-
ment integrated
x x
MD conforming energy meter
integrated
x x
AC SMART App x x
Supported network protocols
Modbus RTU / TCP, OCPP 1.6 (J) Modbus RTU / TCP, OCPP 1.6 (J)
Mobile phone x x
Interfaces
Bluetooth (Low Energy),
WLAN (802.11 b/g/n),
2 x LAN / Ethernet, 1 x RS 485
Bluetooth (Low Energy),
WLAN (802.11 b/g/n),
2 x LAN / Ethernet, 1 x RS 485
Digital inputs
5 x 12 V / 6 mA 5 x 12 V / 6 mA
Digital outputs 4 x 12 V / 100 mA 4 x 12 V / 100 mA
1)
must be present in the domestic installation
