Operating instructions – AC SMART
2 For your safety
2.1 Intended use
The EV charging boxes in the AC SMART product family are designed for
charging electric vehicles and hybrid vehicles. The EV charging boxes can
be installed individually on private property, or installed in larger numbers in
parking lots or underground garages belonging to companies and institutions.
Charge the EV charging boxes with Mode 3 in accordance with IEC 61851-1
and with power plugs in accordance with IEC 62196.
An EV charging box may only be operated if it is installed as stationary on a
wall or a stand. Usage of extension cables is not permitted.
The product is intended for use in accordance with these operating instruc-
tions. Any use that deviates from these operating instructions is considered
improper use.
Observethecountry-specicrequirementssetforthinIEC61439-7,
IEC 61851-1, IEC 61851-22, IEC 61851-21-2, IEC 62196-1, IEC 62196-2
and IEC 63000. Also observe the applicable national regulations.
2.2 Personnel
All work on the domestic installation and electrical installation of the product
must be carried out by an electrician.
2.3 Safety notes
► Check with the responsible grid operator regarding applicable regulations
and provisions for EV charging boxes.
► You can download an acceptance protocol for initial commissioning from
the Weidmüller website.
WARNING!
Risk to life due to electric shock
There is a risk of electric shock when working on the electrical installation of
the product.
► Ensure that the following equipment is present in the domestic installation:
– one residual current protective switch for each charging point in accord-
ance with DIN EN 61008-1, DIN EN 61009-1
– one circuit breaker for each charging point in accordance with
DIN EN 60898,
DIN EN 60947-2
► When working on the electrical installation, ensure that power to the
productandsupplylineareswitchedo󰀨.
► Do not operate the EV charging box without a residual current protective
device in domestic installation, see Chapter 15
► Do not operate the EV charging box without a circuit breaker, see
Chapter 15.
