5 Unpacking and checking the scope of
delivery
5.1 Unpacking the delivery
► Remove all parts of the product from the packaging, including the supplied
documents.
You can use the cardboard with which you lifted the EV charging box out of
the box as a drilling template.
► Keep the packaging in order to store the product in it when it is not
installed, see Chapter 6.
► Dispose of the packaging according to local regulations.
5.2 Checking the scope of delivery
► Check that the delivery is complete and that all parts are undamaged.
1 x
1 x
1 x
SOCKET
ECO
PLUG
4 x8 x 60 mm
1 x
4 x
4 x 18 mm
6 x 60 mm
6 x
1 x
1 x
1 x
1 x
Image 5.1 Scope of delivery for the ECO product line
