Weidmüller AC SMART VALUE Socket - Type Plate

Product description
65
Operating instructions – AC SMART
3.2 Type plate
Type: CH-W-S-A11-S-E
P/N: 2863070000
S/N: ABXX12AB1234567
M/D: DD.MM.YYYY
S/N:
Instruction
Weidmüller Interface GmbH & Co. KG
Klingenbergstraße 26, D-32758 Detmold
Rated Voltage: 400 V
Rated current: 16 A
Type of current: AC
Electrical output: 11 kW
Phases: 3
Frequency: 50-60 Hz
Ambient temperature: - 30° C ... + 50° C
Protection class: IP54
Instruction: www.weidmueller.com
1
2
3
4
5
6
7
14
15
16
17
18
8
9
10
11
12
13
Image 3.2 Type plate
1 Manufacturer
2 Type designation (product variant)
3 Item number
4 Serial number
5 Date of manufacture
6 Rated voltage
7 Rated current
8 Type of current
9 Power rating
10 Connectible phases
11 Nominal frequency
12 Ambient temperature range (operation)
13 IP ingress protection class (dust and water)
14 CE conformity
15 Earthing symbol
16 Disposal information
17 Link to online documentation (QR code)
18 Serial number (QR code)
