Weidmüller AC SMART VALUE Socket User Manual

Product functions
71
Operating instructions – AC SMART
Function or setting option Web server AC SMART App
Integrate EV charging box in a network (LAN/
WLAN)
 
Manage network settings
 
Congureauthenticationmethod
 
Adjust maximum charging current limit during initial
commissioning

–
Monitor charging process

–
Network settings Modbus RTU, Modbus TCP,
Bluetooth communication)

–
Congurationofdigitalinputs

–
Congurationofdigitaloutput

–
CongurationofanOCPPbackendconnection

–
Congurationofload/chargemanagement

–
Firmware update

–
Set system time

–
Resetting the EV charging box to factory settings
 
Restarting the EV charging box

–
4.4 Charging the vehicle
DependingonthecongurationoftheEVchargingbox,chargingispossible
withoutauthentication(Freemode)orwithauthentication.Ifchargingis
possibleonlyafterauthentication,thenthewaysinwhichachargingprocess
canbestarted,interrupted,orendeddependontheauthenticationmethod,
see Chapter 9.3.
4.5 Status information and error display
The status of the EV charging box and any errors are displayed in the web
server and in the AC SMART App. The EV charging box is also equipped with
an LED status indicator.
4.6 Monitor charging process
The technical features of the charging process, such as the electrical values
fortheindividualphases,e󰀨ectivepower,reactivepower,apparentpower,
mains frequency power factor, total power and device temperature can be
displayed in the web server.
