Weidmüller AC SMART VALUE Socket - Connections and Electronic Components

Product description
67
Operating instructions – AC SMART
3.4 Connections and electronic components
ATTENTION!
Damage or fault due to product modications
Removing or modifying the electronic components may cause damage to or
faults in the product.
► Do not modify the electronic components contained in the product.
► Observe the Assembly and installation instructions.
1
2
Image 3.4
1 Power board in the housing base part
2 Control board in the housing cover
