Weidmüller AC SMART VALUE Socket User Manual

Networking and conguring the EV charging box
93
Operating instructions – AC SMART
Resetting the EV charging box to factory settings
All settings and data will be reset to defaults or deleted.
You must be logged in as an Admin. Electrician only!
The EV charging box may not be connected to a vehicle.
You can reset the EV charging box in the web server or via the power supply.
Resetting the EV charging box in the web server
► Click Cong/General.
► Click Start.
► Conrmthereset.
Resetting the EV charging box via the power supply
► Switchtheresidualcurrentprotectivedeviceonando󰀨tentimeswithin
one minute.
The EV charging box will be reset to default settings and restarted
automatically.
Set digital output
Youcanfreelycongurethedigitaloutput.Thefollowingsettingsare
available:
– The output is non-functional.
– The output puts out a high signal if a charging process is active (status C).
► Click Cong/General.
► Select the desired setting.
► Click Save.
9.4 Connecting the EV charging box to an external
device (Modbus)
EV charging boxes in the AC SMART product family can be controlled via
Modbus RTU or Modbus TCP via an external management system. The
external management system is the client. The EV charging boxes are con-
guredasserversupondelivery.Theremaybeonlyoneclient,butmultiple
servers. The Modbus TCP interface can be used by LAN and WLAN.
► Commission an electrician.
► Observe the Assembly and installation instructions.
Prerequisite
