Operating instructions – AC SMART
10 Operating the EV charging box
CAUTION!
Risk of injury if product is damaged
A damaged or incomplete product can lead to malfunctions and hazards.
► Check the EV charging box and its accessories for obvious damage before
each use.
Damage to the charging cable and the EV charging box
Pulling or tearing the charging cable can cause damage to the cable and the
EV charging box.
► To remove the charging cable, always pull on the plug and not on the
cable.
Danger of tripping due to a charging cable lying around
Ifthechargingcableislyingontheoor,peoplemaytripoveritandthecable
may be damaged by crushing or kinking.
► Lay the charging cable so that it cannot be crushed or bent and there is no
risk of tripping.
10.1 Charging the vehicle
The EV charging box is ready for operation and the LED status indicator is
continuously illuminated green. If the LED status indicator is not illuminated
green, then the display is either inactive or the EV charging box is not ready
for operation, see Chapter 12.
Starting the charging process (SOCKET variation)
AlwaysconnectthechargingcabletotheEVchargingboxrst,andthento
the vehicle.
► Connect the charging cable to the charging socket of the EV charging box.
► Connect the charging cable to the vehicle.
Both charging plugs are interlocked. The LED status indicator of the EV
charging box is illuminated blue.
Ifnoauthenticationiscongured(freemode),thenthechargingprocess
will start automatically. The LED status indicator of the EV charging box is
illuminated blue and pulsing.
Ifuserauthenticationiscongured,additionalstepsarerequiredandwill
dependonthetypeofauthentication,seeChapter 10.2.
