Operating instructions – AC SMART
7 Preparing for installation
7.1 Selecting the installation site
Select an installation site that meets the following requirements.
– Flat, vertical wall or stand
– Substrate suitable of supporting at least 100 kg. The substrate must be
able to bear not only the weight of the EV charging box, but must also hold
securely if there is an accidental tensile load, for instance caused by the
charging cable or an impact.
– Sucientspacetooperatetheproduct
– Suitable environmental conditions
► Also observe the safety information (Chapter 2) and the information in the
technical data (Chapter 15).
7.2 Ordering installation
► Contactyourgridoperatortodeterminetheapplicablespecicationsand
provisions for using EV charging boxes in your location.
► CommissionaqualiedelectriciantoinstalltheEVchargingbox.
► Observe the safety information in Chapter 2 as well as the Assembly and
installation instructions enclosed with the EV charging box.
7.3 Tools required
Tools required Recommended
Spirit level
Pin
Drill
Drill bit diam. 8 mm, length > 60 mm
Hammer
Cable cutter
Weidmüller KT 45 R (9202040000)
Sheathing strippers
Weidmüller AM-X (2625720000)
Stripping tool
Weidmüller MULTI-STRIPAX 1.5-6.0S (9204560000)
or Weidmüller MULTI-STRIPAX 6-16 (9202210000)
Crimping tool
Weidmüller STRIPAX PLUS 2.5 (9020000000)
Torx
®
screwdriver T20 Weidmüller SDIT SLIM T20 X 100 (2749720000)
Torx
®
screwdriver T30 Weidmüller SDIT SLIM T30 X 150 (2749740000)
Weidmüller tools are available in our online catalogue at
www.weidmueller.com.
