2.3 Set Commissioning Parameters
This operation is used to set parameters for commissioning, to avoid damage to the
machine tool during its movement.
According to the type of control systems, it can be divided into the following:
Set commissioning parameters for bus control system. (Exclusive to NK280B)
Set commissioning parameters for non-bus control system.
2.3.1 Set Commissioning Parameters for Bus Control System
Before setting commissioning parameters for bus control system, ensure the
following:
Parameter Control System Type is set to 1.
The used terminal board is Lambda 5M.
To set commissioning parameters for bus control system, do the following:
1. To enter into Machine Param interface, press A.
2. To check manufacturer’s parameters, press F2, and input the manufacturer
password.
3. Find and set the following parameters:
Drive Station Address
It should match with toggle switch setting of the driver station address.
Number of each drive station address should be unique, such as X-axis is set 1,
Y-axis is set to 2, and Z-axis is set to 3…
0 is invalid.
Encoder Digit
The encoder digit of a servo motor.
Lead Screw Pitch
It refers to the axial distance between the corresponding points of two adjacent
teeth on the threads.
TravelLimits-Positive / TravelLimits-Negative
The movement range of each axis in X-axis, Y-axis and Z-axis direction.
The system will carry out soft limit in terms of this range in order to protect the
machine tool.
